B760 NAS Motherboard is Suitable for Processor 12/13/14 Generation CPU |2X M.2 NVMe|8X SATA3.0|4X Intel 2.5G Network Port 17 * 17cm Soft Router ITX Mainboard

1. Must work with a good radiator 2. Must connect 24pins+4pins ATX 12V power suppy at the same time to power on. 3. Every new motherboard was tested with radiator totally before shipping, that is why copper plate seems to get traces of thermal grease. 4. Intel i226-V is a new network card, suggest to install newest version of following systems with supportable kernel: pfSense-CE 2.7, OPNsense 23.x, pfSense Plus, OpenWrt, ESXi, Proxmox 8.x, CentOS etc. Please make clear before buying. CPU: support 12th/13th/14th LGA1700 CPU Chipset: B760 BIOS: AMI 128Mb BIOS,ACPI supported, Supports Power on startup Memory: 2*DDR5 SO-DIMM 5600MHz ,up to 96GB SSD: 2*M.2 NVME.8*SATAⅢ,6Gb/s, RAID 0 15 10 Network: 4* I226 2.5G RJ45 Display: 1*DP,1*HD Audio: ALC897 chip, Line out Mic two-in-one interface USB: 4*USB3.2 Gen2, 2*USB3.2 Gen1 3*USB2.0+1*encrypted USB Serial port : 1*COM RS232 Expansion interface: 1*PCIEX4 slot TPM : TPM2.0 hardware encryption (optional) Power supply: ATX 24PIN+4PIN ATX power supply Board size: MINI-ITX(170*170mm) Suitable for 115X fan

Features & Specs

• Chipset Type : Intel B760
• Compatible Devices : DDR5, Nvme
• Compatible Processors : Intel Core i3/i5/i7 12th/13th/14th Gen
• Graphics Card Interface : PCI Express 4.0
• Main Power Connector Type : 24-Pin+8Pin
• Memory Clock Speed : 4800 MHz
• Memory Slots Available : 2
• Memory Storage Capacity : 2 GB
• Number of Ethernet Ports : 4
• Number of Ports : 16
• Platform : Linux, Windows
• Processor Socket : LGA 1700
• RAM Memory Technology : DDR5
• Ram Memory Maximum Size : 64 GB
• System Bus Standard Supported : SATA 3
• Total Number of HDMI Ports : 1
• Total PCIe Ports : 1
• Total SATA Ports : 8
• Total Usb Ports : 4
• USB 2.0 : 2

Item details

• ASIN : B0D7G97ZMC
• Brand : HKUXZR
• Manufacturer : HKUXZR
• Model Name : BK-B760-NAS
• Model Number : BK-B760-NAS
• Warranty Description : One year warranty
