CWWK Firewall Mini PC Intel N Series N100, DDR5 N0 RAM N0 SSD,4 x 2.5GbE i226V LAN,Micro Router Appliance,AES-NI,OPNsense,4*M.2 NVMe

Processor: Intel N100
Memory: 1* SO-DIM DDR5 480OMHZ (compatible with 5200//5600MH2) as large as 32GB
Storage: 1*M.2 NVMex4 (multiple M.2 or mSATA/SATA can be supported through the adapter board)
Graphics: Intel UHD Graphics
Display: HDMI2.1 supports 4096x2180@60Hz
DP1.4 supports 4096×2160@60Hz
Network card: 4*intel i226.V 2.5G network card
Wifi: 1*M.2 KEY E (support Bluetooth/WiFi6 module
USB: 4*USB2.0
Heat dissipation: no fan, two copper tubes heat conduction aluminum shell passive heat dissipation
BIOS: AMI EFI BIOS supports self-starting when calling, GPIO, PXE network calling super
Power Consumption: 15W
Power supply: DC-12V5 (5*25 connector)
Chassis: aluminum alloy material
Extended pin header: 2*4Pin fan header with temperature control, 1*serial pin header, 1*USB pin header, 1*SW (shutdown USB pin header)
Expandable: M.2WiF supports expansion to NVMe/SATA/mSATA hard disk signals
M.2 X4 socket can expand 2/3/4 M.2x1
Size: 145.6mm (L) 145.4mm (W) X 53.6mm (H)
Color: Grey/Black
Installation method: desktop, wall-mounted (contact customer service for additional purchase)
Working environment: -0°C~t70'C relative temperature 5%-85%

Additional details

• Additional Features : Microphone
• Color : N100 4LAN
• Hard Disk Description : SSD
• Hard Disk Interface : Serial ATA
• Hardware Interface : Bluetooth, USB
• Operating System : ESXI, OPNsense, OpenWrt, Unbutun, Windows
• Personal Computer Design Type : Mini PC
• Power Consumption : 15 Watts
• Power Plug Type : Type A - 2 pin (North American)
• Specific Uses For Product : Firewall/Netgate/Softrouting/NAS/VPN
• Style Name : Minimalist
• Total Expansion Slots Quantity : 1
• Video Output : HDMI, DisplayPort
• Video Output Interface : HDMI, DisplayPort

Connectivity

• Connectivity Technology : USB
• Wireless Network Technology : Wi-Fi
• Wireless Technology : Bluetooth, Wi-Fi

Display

• Aspect Ratio : 16:9
• Display Resolution Maximum : 3840x2160
• Display Type : LCD
• Native Resolution : 4096 x 2160
• Resolution : 3840 x 2160

Graphics

• Graphics Card Interface : Integrated
• Graphics Coprocessor : Integrated Intel UHD Graphics
• Graphics Description : Integrated
• Graphics Ram Type : SODIMM

Input Devices

• Human-Interface Input : Dial
• Keyboard Description : Standard Keyboard
• Keyboard Layout : QWERTY

Item details

• ASIN : B0CL5SBWCJ
• Brand : CWWK PC
• Built-In Media : Power supply
• CPU Model Number : N100
• Manufacturer : CWWK
• Model Name : N100
• Model Number : N100
• Processor Brand : Intel
• Video Processor : Intel

Memory

• Memory Clock Speed : 4800 MHz
• Memory Speed : 4800 MHz
• Memory Storage Capacity : 32 GB
• RAM Memory Technology : DDR5
• RAM Type : SODIMM
• Ram Memory Maximum Size : 512 GB

Ports

• Number of Component Outputs : 2
• Total Number of HDMI Ports : 1
• Total Usb Ports : 4

Processor

• Processor Count : 4
• Processor Series : Celeron
